High Speed Granulation Mill, Multi Mill

High Speed Granulation Mill, Multi Mill Operates on the principle of variable force swing beaters having both knife and impact edges rotating within a selected screen to get the required size reduction.

Material fed in the hopper, goes down to the processing chamber where it moves to the periphery and passes through the screen radially and tangentially. Finally, the processed material gets collected in the container kept below the processing chamber.

Output and quality of the final product depends on three main factors: (I) Shape of beaters (knife/impact edges) (II) Speed and (III) Screen.

Multi mill machines are widely used for wet and dry granulation, pulverization etc. These machines find application in pharmaceutical, chemical, bulk drug, cosmetic, dyestuffs and food processing industries.

Multi mill is used for high speed Granulating, Pulverizing, Mixing, Shredding and Chopping, etc, of a wide range of wet and dry materials without special attachments. This machine utilizes the principle of variable force swing hammer blades having both knife and impact edges rotating with a carefully selected screen to control size reduction.

Flow path of material in vertical rotor machine is streamlined. During commuting, material entering the chamber travels to the periphery and passes through the screen tangentially and radially avoiding chocking and temperature rise.

Special Features

• Machine Portable on Castor wheels.



• High output with Process uniformity.



• Direction of the Blade rotation can be changed using a Reversing switch for Hammer or Knife operation.



• Multiple combinations of Screens / Speeds / Number of Blades.



• Direction of blade rotation for every Product type.



• Higher Screen opening area for Higher Throughput.



• Easy Dismantling and Cleaning of all Components reducing.



• Production Downtime and increasing Productivity
  Wide range of SS perforated and Wire knitted screen available for every Product type.



• Minimal material handling resulting in Total Dust free operation.



• Additional perforated screen at the bottom of pulverizing chamber ensuring Higher Fineness and Controlled Size of Granules.



• Built in Variable Frequency Drive for multiple speeds.
