Product Structure:


| model | displacement (1450g/ min50hz) | displacement (1750g/ min60hz) | Number of cylinders * bore * stroke | Maximum operating current | Motor voltage | Maximum power | Weight | Suction pipe connection: | Exhaust pipe connection: |
| YBF4H-15.2ZR | 73.6m3/h | 88.83m3/h | 4*70*55mm | 31.0Amp | 380..420 V YY/3/50HZ 440..480 V YY/3/60HZ | 18.1KW | 196KG | 42mm 1-5/8" | 28mm 1-1/8" |
| YBF4H-25.2GR | 73.6m3/h | 88.83m3/h | 4*70*55mm | 45.0Amp | 24.9KW | 213KG | 54mm 2-1/8" | 28mm 1-1/8" | |
| YBF4G-20.2ZR | 84.5m3/h | 101.98m3/h | 4*75*55mm | 37.0Amp | 21.5KW | 204KG | 54mm 2-1/8" | 28mm 1-1/8" | |
| YBF4G-30.2GR | 84.5m3/h | 101.98m3/h | 4*75*55mm | 53.0Amp | 30.1KW | 220KG | 54mm 2-1/8" | 28mm 1-1/8" |
