XGMA высокопроизводительный гусеничный бульдозер 160HP XG4161L
- Категория товара: >>>
- Поставщик (Оптовый магазин): Cruking,Engineering,Equipment,(Xiamen),Co.,Ltd.Cruking,Ltd.
Поделиться:
Описание и отзывы
Характеристики
XGMA Hot Sale Bulldozer XG4161L
CONTACT WAY: WHATSAPP +8613959261266 SALLY
FEATURES
Equipped with a hydraulic drive system and an advanced structure, which provides reliable performance and convenient and flexible operation.
Applied with the travel system of walking beam suspension design, applicable to the uneven and bumpy working site.
Equipped with a straight-tilting shovel as standard as well as U-shovel and angle shovel as options, all provided with the well durable blade.
Optionally equipped with the ripper, (3-tooth or 1-tooth available),u-shovel, angle blade, air conditioning, rear ripper, ROPS frame, forest cab, etc.
PARAMETERS
| Description | Unit | XG4161L | XG4221L | XG4321L | ||
| Engine | Model | type | Weichai WD10G178E25 | NT855-C280 | NTA855-C360 | |
| Rated speed | rpm | 1850 | 1800 | 2000 | ||
| Rated power | kW | 131 | 162 | 235 | ||
| Fuel consumption | g/kW.h | 223 | 212 | 213 | ||
| Travel Speed | Forward | I | km/h | 0-3.8 | 0-3.6 | 0-3.6 |
| II | km/h | 0-6.6 | 0-6.5 | 0-6.6 | ||
| III | km/h | 0-10.6 | 0-11.2 | 0-11.5 | ||
| Reverse | I | km/h | 0-4.9 | 0-4.3 | 0-4.4 | |
| II | km/h | 0-8.5 | 0-7.7 | 0-7.8 | ||
| III | km/h | 0-13.6 | 0-13.2 | 0-13.5 | ||
| Work Equipment | Blade height | mm | 1168 | 1315 | 1590 | |
| Blade width | mm | 3416 | 3725 | 4130 | ||
| Blade capacity | m3 | 4.5 | 6.4 | 10.4 | ||
| Max. depth | mm | 545 | 540 | 560 | ||
| Max. lift | mm | 1095 | 1210 | 1560 | ||
| Max. tilt adjustment | mm | ≥400 | ≥735 | 1000 | ||
| Pitch adjustment | 55 | 55 | 55 | |||
| Ripper (Optional) | Teeth | 3 | 1 or 3 | 1 or 3 | ||
| Max. digging depth | mm | 572 | 666 (3 teeth) | 842 (3 teeth) | ||
| Max. lift | mm | 702 | 555 (3 teeth) | 883 (3 teeth) | ||
| Weight | kg | 1709 | 2900 (3 teeth) | 5350 (3 teeth) | ||
| Specification | Min. ground clearance | mm | 400 | 405 | 500 | |
| Ground pressure | Mpa | 0.069 | 0.077 | 0.104 | ||
| Min. turning radius | mm | 3100 | 3300 | 3940 | ||
| Grade ability | ° | 30 | 30 | 30 | ||
| Operating weight | kg | 17100 | 23450 | 34390 | ||
| Productivity | m3/h | 247 | 330 | 480 | ||
| Overall Dimensions (L*W*H) | Basic | mm | 5188*3416*3060 | 6510*3725*3325 | 6603*4130*3708.5 | |
| With ripper and ROPS | mm | 6215*3416*3060 | 6793*3725*3400 | 8916*4130*3708.5 (1 tooth) | ||
8586*4130*3708.5 (3 teeth) | ||||||
IMAGES
