Высокоточная цилиндрическая шлифовальная машина M1320 для металла
- Категория товара: Cylindrical Grinding Machines >>>
- Поставщик (Оптовый магазин): Shandong,Luzhong,Machine,Tool,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Specification
Cylindrical grinding machine | M1320-1000 | |
Diameter of grinding | Dia.8~200mm | |
Maximum grinding length | 1000mm | |
Maximum spindle load-bearing | 50kg | |
Maximum travel of working table | 1080mm | |
Speed of working table | 100~4000mm/r/min | |
Rotary angel of working table | -3~+7° | |
Rotary angel of headstock | -30~90° | |
Rotary angel of grinding wheel | 180° | |
Center height | 125mm | |
Center sleeve taper | 3# | |
Grinding wheel size | 400*40/50*203 | |
Speed of headstock | 60、85、230、120、170、460r/min | |
Speed of grinding wheel | 1780r/min | |
High-speed travel of grinding wheel | 20mm | |
Maximum travel of grinding wheel | 150mm | |
Feeding rate of grinding wheel handwheel per grid | 0.005mm | |
Feeding rate of grinding wheel handwheel per rev | 1mm | |
Power of grinding wheel motor | 4kw | |
Power of headstock motor | 0.25/0.37kw | |
Power of oil pump motor | 0.75kw | |
Power of cooling motor | 0.125kw | |
Dimension (length * width * height) | 3100*1450*1650 | |
Weight | 3000kg | |
Roundness 0.002mm Cylindricity 0.003mm Roughness Ra0.32 | ||
Details Display
Recommend Products
Company Profile
VR
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
