Гибочный станок Shijiazhuang Hebei Cnc
US $9600-$22000
CNC автоматический стальной проволоки Бендер железа арматура автоматический бар гибочный станок 4-12 мм для строительства
- Категория товара: Rebar Bending Machine >>>
- Поставщик (Оптовый магазин): Maanshan,Bamboo,CNC,Machinery,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Product description
Rebar hoop bending machine, low equipment failure rate, fast steel bending speed, low power without rib damage, low noise, vibration light; reliable operation and other functions.Double operation, light and flexible, convenient movement, adapt to the production of large construction units and stirrps of steel mills; high efficiency, several times the manual bending, can produce 4-6 tons per day, length is accurate for large volume and factory operation, wide angle adjustment range, any 360 degrees adjustment, can bend square, trapezoidal stirrps and U hook, suitable for construction, bridge, tunnel and other engineering components.
Product characteristics：
1. double-line hoop transmission system greatly improves the production efficiency.
2. double-leaf bending mode realizes the rapid positive and reverse bending of the steel bar and improves the bending quality.
3. mechanical shear, large shear strength and high reliability.
4. has powerful databases with hundreds of graphics storage memory.
5. reinforcement straightening.Set feet.Bend hoop.Cut off and plate bar and other functions are perfectly combined, and meet the accuracy requirements of reinforcement processing, to truly realize the multi-use of one machine.
6. This equipment is widely used in high-speed, railway, tunnel, housing construction projects.
7. has a maximum capacity of 1,800 stirrups / 1 hour.Equivalent to the productivity of multiple workers, while maximizing material savings.
8. has hundreds of graphics storage databases and is free to edit graphics.
9. split formula set.Move the knife, only need to replace the blade, greatly reduce the cost.
10. control system: Panasonic PLC, Panasonic touch screen, imported frequency converter.
Technical parameters
Scope of steel processing | Single-line curved diameter 5-12mm Double curved diameter5-10mm |
Maximum traction speed | 110 meter/min |
Maximum bending speed | 1000° second |
Equipment power | 26KW |
Bend direction. | Two-way |
tolerances | ±1mm,±1° |
Maximum bending angle | 180° |
Storage chart | 500+ |
Production efficiency | 60 m/min |
Production capacity | 200 * 200 mm 2200 pieces/hour |
Oversize | 3500*1000*1700mm |
Weight | 3.0ton |
