Product Overview
The vehicle chassis is equipped with a tank body and an oil discharge pipeline to form an oil transport vehicle; On the basis of the oil truck, the pump system is added to form the fuel truck. The tank car is normal temperature (normal atmospheric pressure metal tank environment working temperature is -40 - +50℃, non-metal tank is -20 - +40℃), atmospheric pressure tank car, divided into two categories, semi tanker, the main shipment of gasoline, diesel oil, crude oil and lubricating oil and other liquid oil.
Product Paramenters
Overall Dimension | 11990mm*2495mm*3570mm(LxWxH) | |
Payload | 20ton | |
Dead Weight | 20250kg | |
Front Overhang | 1500mm | |
Rear Overhang | 3315mm | |
Wheelbase | 5825mm+1350mm | |
CHASSIS | ||
Chassis Brand&Model | SINOTRUK HOWO ZZ1257M5841W | |
Axle Number | 3 axles, driving type 6x4 | |
Cab | HW76,left hand drive,air-conditioner,one sleeper | |
Engine | SINOTRUK WD 615.87,290HP, | |
Gear Box | HW10, | |
Traversing Mechanism | German ZF8098,turning system pressure 18MPa | |
Clutch | 430,Single-plate dry clutch | |
Wheels and tries | Rim 8.5-20 | |
Brakes | Dual circuit pneumatic | |
Tank Volume | 22cbm | |
Steel thickness | 5mm | |
Accessory | 2 discharge pipes | |
