Китай, высокое качество, вертикальный удлинитель шпинделя, водяной вертикальный подъемный клапан

Китай, высокое качество, вертикальный удлинитель шпинделя, водяной вертикальный подъемный клапан

Категория товара: Gate Valves >>>
Поставщик (Оптовый магазин): Shanxi,Goodwill,Industrial,And,Trading,Co.,Ltd.

Цена:157,00 $ - 169,00 $

Стоимость в USD:Узнать цену

Количество:

Купить

В избранное

Описание и отзывы

Характеристики

CAST IRON BUTTERFLY VALVES
Material Specification
Part	Material	EN Spec.
Body	Cast Iron	A126 Class B
	Ductile Iron	A536 Gr.65-45-12
Disc	Ductile Iron	A536 Gr.65-45-12
	Bronze	B148 C95400
	Stainless Steel 304	A351 CF-8
	Stainless Steel 316	A351 CF-8M
Shaft	Stainless Steel 410	A276 S410 00
	Stainless Steel 431	A276 S431 00
Seat Ring	EPDM /NBR
O-Ring	EPDM /NBR
Bushing	PTFE
	Bronze	B62 C83600
Valve Standard
ISO 5752/BS5155/BS EN 593/MSS SP-67/API 609
Pressure Temprature and Rating
Working Pressure	16bar/27.5bar
Testing pressure	Shell: 24bar/37.5bar
	Seal: 17.6bar/27.5bar
Working Temperature	-20°C to 110°C EPDM Seat
	-10°C to 80°C NBR Seat
Suitable Media	Water, Oil& Gas
Description Products
Size	DN40-DN1200
End flange	ANSI B 16.1, EN 1092, AS 2129
Face to face	ANSI B 16.10; EN 558-1 Series 20
Top flange	ISO 5211
Related products	1. Carbon steel nipples and sockets	2. Flanges
	3. Carbon steel butt-welding fittings	4. Pipes
	5. High-pressure fittings	6. Valves
	7. P.T.F.E .thread seal tape	8. Brass fittings
	9. Ductile iron pipe fittings	10. Copper fittings
	11. Grooved fittings	12. Sanitary fittings, etc.
Certificate	BSI, ISO9001:2008
Applications	Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc.
Buyer’s drawings or designs are available.
Package	1. Cartons without pallets.
	2. Cartons with pallets.
	Or as buyer’s requirements.
Delivery detail
According to the quantities and specifications of each order.
Normal delivery time is from 30 to 45 days after receiving the deposit.

Established in 1991 and as one leading professional manufacturer of malleable iron pipe fittings, we, Shanxi Goodwill Industrial & Trading Co., Ltd. have been producing and exporting 100% of our products to worldwide markets. Our business range and activities as follows: Our factory produce 1) valves and fittings: a) Models: beaded / beaded with ribs, banded / banded with ribs b) Types: galvanized (hot dipped), normal black, shining black c) Grades: heavy series, standard series, light seriesd) Standards: i) DIN (Germany) standard, DIN 2950/1692/2999ii) BS (British) standard, ISO49 / ISO5922 / ISO7/1iii) ANSI standard, ASTM B16.3 B16.14 B16.39 / B1.20.12) Malleable casting products: produce according to supplied samples or drawings We supply and export various kinds of flanges, steel couplings / nipples, heaters / radiators, SS fittings, brass / copper fittings from our sister factories or partnership manufacturers Our advantages and guarantee are S-G-W: 1) Satisfied quality 2) Great cooperation3) Workable prices We sincerely hope to establish long term and mutual beneficial cooperation with any buyer and friend all over the world, please feel free to contact us at your convenient time.
