3840x2160 4K VGA Type-c PD Docking Adapter USB HUB
Product Description
| Brand Name | ZOGUO/OEM | |||||||||||
| Model No. | ZG-HB22 | |||||||||||
| Product Name | USB C HDMI VGA Hub | |||||||||||
| Housing Material | Aluminum Shell | |||||||||||
| Package | Polybag,Foil bag,Blister box , Gift box , OEM packaging | |||||||||||
- Mirror and Extend Screens: This 5in1 USB-C Hub Provides a connection from your USB-C Thunderbolt 3 compatible device to your HDMI or VGA enabled TV/monitor/projector so that you can enjoy large visual big and VGA can be connected simultaneously, but only extend same screens in external displays, a VGA or HDMI cable is required, but not included.
- High performance UHD 3840*2160 4K video transmission: when you connect HDMI port to displays individually, HDMI output resolution max reach up to 3840x2160@30Hz while VGA max support resolution 1920x1080@60Hz, when HDMI and VGA connected together, only 1080p output
- USB3.0 USB-C PD Multiport Ports: This Malfunction Hub Attached an USB3.0 ports providing a Max Data Transmissions 5Gbps for you to connect your USB Flash U- or other USB USB-C Female port, offers a possibility to charge your laptops while you are using your device
- HDMI Audio Video Synchronous transmission: If you connect HDMI output to your HDTVs or Monitors with Audio, the Audio and Video can be transmitted together, But if you connect to HDMI monitors without audio or VGA monitors, please use audio of your input devices
- USB Type-C multifunction hub wide compatibility: our this hub work well Huawei mate Book, Dell XPS 13, 15, Samsung and other devices supporting DP alternate Mode
Specification:
1xHDMI V1.4 Port Female,Support Max Resolution to 3840x2160 UHD 4K@30Hz
1xVGA 15pin Port Female,Suport Max Resolution to 1920x1200 FHD @60Hz
1xUSB3.0 Port Female,Data transmisions Max Reach to 5Gbps.Supporting Data Transmitting Simultaneously and Max 900mA Power,1xUSB2.0 Port Female,Data Transmission Rate Max to 480Mbps.
1xUSB-C PD Port,Supporting charging your laptop while you are using your connecting device via a Charger
1xVGA 15pin Port Female,Suport Max Resolution to 1920x1200 FHD @60Hz
1xUSB3.0 Port Female,Data transmisions Max Reach to 5Gbps.Supporting Data Transmitting Simultaneously and Max 900mA Power,1xUSB2.0 Port Female,Data Transmission Rate Max to 480Mbps.
1xUSB-C PD Port,Supporting charging your laptop while you are using your connecting device via a Charger
Compatible Lists:
-2017 Macbook Pro
- 2016 MacBook Pro(With Touch Bar)
- 2015 MacBook 12"
- ChromeBook Pixel
- Dell XPS 13-9350-R1609 13.3", XPS 15
- Acer V15 Nitro
- ASUS GA-Z170X
- HuaWei MateBook
-hp SpecterX2
-ASUS Zenbook 3
-lenovo miix510
-Acer V17 Nitro
-Xiaomi Air 12
-Samsung S8
-Samsung Note 8
-HuaWei P20
-HuaWei Mate 10
- 2016 MacBook Pro(With Touch Bar)
- 2015 MacBook 12"
- ChromeBook Pixel
- Dell XPS 13-9350-R1609 13.3", XPS 15
- Acer V15 Nitro
- ASUS GA-Z170X
- HuaWei MateBook
-hp SpecterX2
-ASUS Zenbook 3
-lenovo miix510
-Acer V17 Nitro
-Xiaomi Air 12
-Samsung S8
-Samsung Note 8
-HuaWei P20
-HuaWei Mate 10
Important Notes:
1:All USB-C Connected Device must support “DisplayPort Alternate Mode” (DP Alt Mode) via USB-C,not compatible with devices which do not support the protocol of DP Alt Mode.
2:The Hub can be connected with smarthones or tablets with models listed in Compability,but for the compability for other phones and tablets,please consult with us before buying.
3:If you would like to display 4k separately in your external displays,please make sure that you have 4K cable,4k source and 4k monitors.
4:If you connect HDMI and VGA to output displays together,it can only show same content in your two connected displays.
5:The USB-C Female port in the hub can only used for charging,can not be used for data.
2:The Hub can be connected with smarthones or tablets with models listed in Compability,but for the compability for other phones and tablets,please consult with us before buying.
3:If you would like to display 4k separately in your external displays,please make sure that you have 4K cable,4k source and 4k monitors.
4:If you connect HDMI and VGA to output displays together,it can only show same content in your two connected displays.
5:The USB-C Female port in the hub can only used for charging,can not be used for data.
