Product Introduction
This packing machine design and maintance is very simple
This machine is suitable for all kinds of kiln.
Only need 4 labors to operate but no need wooden pallets.
Technical features:
The automatic brick unloading and packing machine is the equipment for the automatic unloading and packing of finished bricks after the firing of the sintered brick enterprises. The automatic brick unloading and packing unit mainly focuses on the adhesion and deformation of the sintered bricks after firing. A set of reasonable brick unloading, marshalling, palletizing, and packaging process plans. This plan is the first and mature post-kiln automation solution in China. The unit adopts a large number of advanced control technologies. The horizontal movement of the unloading and palletizing devices and the rotation of the gripper are all controlled by servo motors. The servo control system can not only achieve rapid and stable action, but also according to the brick stack after firing. Adjust the actual situation to improve the equipment’s ability to adapt to the brick stack; the brick unloading clamp is a new structure that has obtained a national invention patent. It can effectively solve the problem of adhesion between the upper and lower layers in the process of unloading bricks and prevent the lower bricks from being It moves during the process of clamping the bricks by the hand to ensure the reliability of the brick unloading machine. The guide rails used in the equipment are all machine guide rails, which have long service life and easy maintenance. The palletizing clamps are lifted by soft belts, and the movements are soft and no impact to ensure the reliability of the equipment.
Technical Parameters:
Technical Parameters:
1, the single-layer unloading cycle is less than 45 seconds;
