Who we are？

Cassman specialized in Micro/Commercial brewery equipment, Distillery equipment. With CE, ISO certifications, our equipment has been widely exported to more than 60 countries and regions, such as Germany, Belgium,UK, the United States, Russia, Canada, Australia, Southeast Asia, etc. With long-term cooperative and exchange relations with the the American Brewers' Association, Japanese Brewers' Association, Cassman will provide the best design in brewing technology and cost-effective equipment.

1000L Beer Brewing System
Brewing system	Components	Capacity	Specification
Grinding system	Miller	300KG/H	Double Roller
Heating System	Boiler	100KG/H	Electric,Gas,Oil,Coal Type/CE certification
Brewhouse system	Mash/Lauter tun	1000L	Heating source:Steam,Electric,Gas Material: SUS304/Red copper Interior thickness :3mm Exteior thickness:2mm
		Brew Kettle/ Whirlpool Tank		1000L
		Hot Water Tank		2000L
		Plate Heat exchanger	10SQM	Stainless steel plate
Fermentation system	Fermentation Tank	1000L/2000L	Top manhole/Side manhole Drying hop port Dimple Plate Cooling jacket Carbonation port to fill CO2
Fermentation system		Yeast Adding Tank	10L	SUS304 Stainless Steel
Cooling System	Glycol Water tank	3000L	Providing the ice water for cooling down the wort and beer
		Chiller	10HP	UL/CE certified electric elements,Copeland compressor
		Pump	3T	Ice water circulation
Cleaning system	Disinfection Tank	100L	SUS304 full welded
		Alkali Tank		100L
		Pump		3T
Control system	Control Cabinet	PID/PLC	Manual/Semi-automatic/Automatic
Optional	Auger System
	Optional	Grist Cabin
		Grist Hydrator
		Beer Filter Unit
		Bright Tank Unit
		Beer keg filling and washing machine, bottling machine
		Other Facilities: Beer kegs Water treatment for brew water Pasteurization System
Technical Parameter	Power: Customise -design Voltage:Cusomized Floor space:We can device a layout based on your floor plan

Cassman Brewhouse Configuration
No.	Brew Length	Vessels	Configuration	Heating	Remark
1	100L	2	Mash/Lauter+Kettle/Whirlpool	Electrical/Steam/Gas	With all the necessary pipelines,valves, pumps, heat exchanger, pump, work platform,control system etc. US-3bbl~60bbl available
2	200L	2	Mash/Lauter+Kettle/Whirlpool	Electrical/Steam/Gas
3	300L	2	Mash/Lauter+Kettle/Whirlpool	Electrical/Steam/Gas
4	500L	2	Mash/Lauter+Kettle/Whirlpool	Electrical/Steam/Gas
5	500L	2	Mash/Kettle+Combined Lauter/Whirlpool	Electrical/Steam/Gas	Germany style
6	500L	3	Mash+Lauter+Kettle/Whirlpool	Electrical/Steam/Gas	Individual three vessels
7	1000L	2	Mash/Lauter+Kettle/Whirlpool	Steam/Gas	Hot water tank as option
8	1500L	2	Mash/Lauter+Kettle/Whirlpool	Steam/Gas	Hot water tank as option
9	1500L	3	Mash+Lauter+Kettle/Whirlpool	Steam/Gas	Individual three vessels
10	2000L	2	Mash/Lauter+Kettle/Whirlpool	Steam/Gas	Hot water tank as option
11	2000L	3	Mash+Lauter+Kettle/Whirlpool	Steam/Gas	Individual three vessels
12	2000L~5000L	4	Mash+Lauter+Kettle+Whirlpool	Steam	Individual four vessels

10BBL Brew House System

* Mash tun+Lauter Tun + Boil Kettle + Whirlpool Tun
* Mash(kettle) Tun + Lauter Tun + Boil Kettle/Whirlpool Tun
* 20BBL Hot water tank for option
* Lauter tun with milled false bottom, VFD motor, Sparging and CIP pipe. Level gauge
* Mash tun with electric heated or steam jacket. VFD motor for option.Level gauge
* 15 square meter Plate heat exchanger
* 5000L/H Sanitary Centrifugal pump
* Digital control panel or PLC control system
* SUS 304 tank, pipe, valves etc.
* SUS 304 platform and integrated stairs.

Cassman Brewing equipment has been widely exported to more than 60 countries and regions, such as Germany, Belgium,UK, the United States, Russia,Canada, Australia, Southeast Asia, etc. With long-term cooperative and exchange relations with the the American Brewers'Association, Japanese Brewers' Association, Cassman will provide the best design in brewing technology and cost-effective equipment.

Established in 2016, Jinan Cassman Machinery Co., Ltd. is located in the High-tech Zone, Jinan City, Shandong Province, we mainly engaged in beer equipment, whiskey distillery equipment, biological fermentation and environmental protection equipment, etc. Jinan Cassman is a production-oriented enterprise with R & D, Manufacture, Sales and Service capabilities. There are more than 40 production employees, more than 10 middle and senior technical personnel, and 8 after-sales service personnel. With the German TUV Rheinland certification, Cassman can design and produce pressure vessels in accordance with the EU CE-PED standard.

The factory covers an area of nearly 8,000 square meters and it has three processing workshops: container processing, welding and cutting, and assembly and commissioning. It is equipped with laser cutting machines, CNC machines, argon arc welding machines, automatic polishing machines, stainless steel uncoiling & bending machines, pressure vessel detectors and other advanced stainless steel processing and assembly tools.

CASSMAN SERVICE

Warranty:
Equipment warranty includes tank warranty, electric parts warranty, auxiliary parts warranty, etc.
1, Cassman provides 3-5 years warranty for the main tank, 1 year warranty for electrical components and auxiliary parts, etc., and lifetime after-sales service.
2, In order to ensure the normal operation of the brewery, we can provide a separate set of spare parts according to the customer's request, customers can replace parts in case of abrasion damage.

Maintenance:
During operation, daily maintenance for the equipment is important. Cassman will provide maintenance guide., if need, we can send engineer to customer's site for repair and maintenance.

Beer equipment model selection:
1, Based on years of experience, Cassman can provide standard models of beer brewing equipment. We have mature experience in brewing technology and equipment design.
2, Cassman can provide custom-made service as per customer's requirement. including customize brewhouse system, fermentation tank, brite beer tank, coffee equipment, whiskey distillation equipment, stainless steel tank, etc.

Brewery design:
Cassman can help to design layout for newly built brewery, and we will supply P&ID drawings, electrical connection diagrams,flow chart, tank drawings, etc. , 3D drawings are also available if needs.

Installation:
Cassman has 6 to 8 experienced technical engineers, we can provide on-site installation and debugging instruction as percustomer's needs.
1, To ensure good after-sales service, we will appoint the same technical personnel to debug and load the equipment beforedelivery,
2, For single tank, if on-site installation service is unnecassary, Cassman will provide equipment drawings and installation guides so that customers can install by themselves.

FAQ

1: Q: How many years does your warranty?
A: The main beer machine for 3 years, auxiliary ones for 1 year.

2:Q: Do you have any certifications?
A: We have CE-PED, TUV certifications

3 Q: How many countries you have exported to ?
A: We have exported our brewing equipment to more than 50+ countries.

4 Q: Is it possible to supply installation in my country?
A: Yes, our engineer will fly to your brewery to help with your installation and beer brewing.
