In general, railway screw spikes are used for fastening sole plates and ribbed tie plates to wooden railway sleepers. As to concrete railway sleepers, the railway screw spikes are used in combination with plastic dowel pressed in the concrete sleepers, indirect or direct fastenings of rails on concrete and wooden sleepers. The railway screw spikes may only be produced in a hot forming operation. The different shapes of the head correspond to the pass form of the respective spanner used for fastening and loosening of the railway screw spikes. Manufacturing railway screw spikes cost more than railway dog spikes, but railway screw spikes have many advantages, such as greater fixing power, approximately twice than that of dog spike and can be used in combination with spring washers.

1. Ss series railway screw spike according to UIC864-1

• Grade: 4.6, 5.6, 8.8


• Material: Q235, 35#, 45#


• Surface Treatment: Plain (oiled), black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing: 25KG plastic bags and wooden pallets or according to clients’ requirements

2. ASTMA66-87 Standard Railway Screw Spike

We can produce ASTMA66-87 standard railway screw spikes for USA market, the production technology of ASTMA66-87 standard railway screw spikes is cold bending 90 degree without cracks.

• Standard strength 65000PSI or high strength 100000PSI is available.


• Diameter: 3/4”, 7/8”, 15/16”


• Length: 5-1/2”, 6”, 7”, 8”, 10”


• Grade: 4.6, 5.6, 8.8


• Material: Q235, 35#, 45#


• Surface Treatment: Plain (oiled), black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing: 25Kg plastic bags and wooden pallets or according to clients’ requirements

3. Railway Screw Spikes with Big Disk

• Diameter: 22mm, 23mm


• Length: 115mm, 133mm, 178mm


• Grade: 4.6, 5.6


• Material: Q235, 35#


• Surface Treatment: Plain (oiled), Black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing: 25Kg plastic bags and wooden pallets or according to clients’ requirements

• Grade: 4.6, 5.6


• Material: Q235, 35#


• Surface Treatment: Plain(oiled), Black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing:25Kg plastic bags and wooden pallets or according to clients’ requirements

5. Railway screw spikes for wooden sleeper (high tension screw spike)

• Size: 15/16×6-1/2


• Surface Treatment: Plain (waxed), Black painting


• MOQ: 5000PCS


• Packing: 38PCS in 50LB plastic keg

High Tension Screw Spike

Full size carbon steel screw spikes shall stand being bent cold 45 degree around a pin three times, the spike’s diameter without crack on the outside of the bent portion.

• Material: 45#, heat treatment

6. Coach Railway Screw Spike

Coach screw spikes are used for the mining industry in South Africa.

• Diameter: 18mm


• Length: 65mm, 75mm


• Material: Q195, Q235


• Surface Treatment: Zinc


• Grade: 4.6


• MOQ: 50000PCS


• Packing: 25Kg plastic bags and wooden pallets or according to clients’ requirements

7. DHS35 Railway Screw Spike

DHS35 railway screw spike, supports the use of the SKL14 rail fastening system

• Diameter: 24mm


• Lengthg: 158mm, 161mm


• Grade: 4.6, 5.6, 8.8


• Material: Q235, 35#, 45#


• Surface Treatment: Plain (oiled), Black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing: 25Kg plastic bags and wooden pallets or according to clients’ requirements

8. Round Thread Type Railway Screw Spike

• Railway screw spike with round thread, according to the standard NF-F 50014


• Grade: 4.6, 5.6, 8.5


• Material: Q235, 35#, 45#


• Surface Treatment: Plain(oiled), Black painting, Zinc, HDG


• MOQ: 5000PCS


• Packing: 25Kg plastic bags and wooden pallets or according to customers’ requirements

9. Timber Drive Railway Screw Spike

Tiber drive spikes can reduce installation and maintenance costs. The spikes are used for timber construction highway crossing planks and panels, bridge and trestle guard rails, motor car set-off, docks, etc. The washer head is single forged and the excellent holding power of threads provides tight installation. The spikes are easily installed, driven with a maul or pneumatic spike driver. They cannot be overdriven and are easily removed for reuse with a hand or power tool. The driven spikes are available for a wide variety of installations and maintenance of way, and meet with the standard ASTMA66-87, cold bending 90 degree without crack.

• Main Size: 5/8×10 and 7/8×7


• Grade: 5.6


• Material: 35#


• Surface Treatment: Zinc or according to clients’ requirements


• MOQ: 5000PCS


• Packing: 200LB kegs and wooden pallets or according to clients’ requirements

10. Slotting Head Railway Screw Spike

Railway screw spikes with slotting head, as per UIC864-1

• Size: 24×131 and 24×150


• Grade: 4.6


• Material: Q235


• Surface Treatment: Plain, Black painting or according to clients’ requirements


• MOQ: 5000PCS


• Packing: Plastic bags and wooden pallets
