Best Price Crawler Bulldozer HBXG 13 Ton 3.1M3 Industrial Bulldozer SD5K for sale
Contact Way
Product Overview
1. SD5K is track-type total hydraulic bulldozer with semi-rigid suspended, electronic controller tier III engine, dual-circuits,
electronic control hydrostatic driving system, electric control heart closing load sensing implement hydraulic system.
2. Power-Angle-Titling blade, automatic control independent cooling system. Thins model is equipped with electrical controlled engine of full power matching pattern, with stepless speed change and pivot steering function, modular design and easy to repair and maintenance; the electric proportional control walking system and work device make the operating precise and comfortable.
3. Human-computer interaction instrument display, intelligent service system, fully sealed air conditioning cab. It can be
equipped with three shanks ripper. It is an ideal machine in exquisite or heavy load working such as harbor construction,
communication construction, stadium, electric power project, city and town earth moving, backfill, modeling and leveling working.
electronic control hydrostatic driving system, electric control heart closing load sensing implement hydraulic system.
2. Power-Angle-Titling blade, automatic control independent cooling system. Thins model is equipped with electrical controlled engine of full power matching pattern, with stepless speed change and pivot steering function, modular design and easy to repair and maintenance; the electric proportional control walking system and work device make the operating precise and comfortable.
3. Human-computer interaction instrument display, intelligent service system, fully sealed air conditioning cab. It can be
equipped with three shanks ripper. It is an ideal machine in exquisite or heavy load working such as harbor construction,
communication construction, stadium, electric power project, city and town earth moving, backfill, modeling and leveling working.
Product Paramenters
Model | SD5K(130HP) | Rated revolution(rpm) | 2200 |
Dozer | Power-Angle-Tilting blade | Rated power(kw) | 97 |
Operation weight(kg) | 13100 | Max.torque(N.m/rpm) | 570/1450 |
Ground pressure(kpa) | 45 | Rated fuel consumption(g/kw.h) | 190 |
Track gauge(mm) | 1790 | Undercarriage system | track-type hydrostatic bulldozer with semi-rigid suspended |
Min.ground clearance(mm) | 315 | Number of track rollers(each side) | 7 |
Gradient | 30°/25° | Number of carrier rollers(each side) | 2 |
Dozing capacity(m³ ) | 3.1 | Pitch(mm) | 190 |
Blade width(mm) | 3060 | Width of shoe(mm) | 510 |
Max.digging depth(mm) | 460 | Gear | |
Overall dimensions(mm) | 4922×3060×2999 | Forward km/h | 0-10.5 |
Engine Type | WEICHAI WP6G125E332 | Backward km/h. | 0-10.5 |
Details Images
