Цифровой измеритель уровня сигнала 5 ~ 870 МГц 64QAM 256QAM CATV с MER и

Цифровой измеритель уровня сигнала 5 ~ 870 МГц 64QAM 256QAM CATV с MER и

Категория товара: Level Measuring Instruments >>>
Поставщик (Оптовый магазин): Ningbo,Snow,Sea,Optoelectronic,Technology,Co.,Ltd.

Цена:220,00 $ - 225,00 $

Стоимость в USD:Узнать цену

Количество:

Купить

В избранное

Описание и отзывы

Характеристики

SNP-S200/S200D CATV Digital Signal Level Meter

Specifications

CATV Meter Signal Level Meter
MER, BER, TILT, A/V, C/N, Average Power, Trunk line Voltage,

Features

1. A test instrument applicable for the maintenance of CATV (Analog, Digital measurement, TILT) system;

2. Compact, light-weight, easy to carry;

3. With dual-channel measurement display, it is convenient and pragmatic;

4. Able to measure MER, BER, Signal Level, Channel Power, V/A, C/N, FM, Trunk Voltage

5. Channel and single frequency mode

Technical Specifications

Model	SNP-S200	SNP-S200D
Digital DVB
Frequency scope	47~870MHz	5~870MHz
Modulation	DVB-C/ITU-T
Support	64QAM / 256QAM (option)
Digital average power	30dBuV ~ 110dBuV
Precision	+2dB
Symbol rate	1MS/S-7 MS/S
Modulate error rate (MER)	22dB ~ 39dB
Bit error rate (BER)	RS 1E-3~1E-9
Analog TV
Frequency scope	46/5~870MHz
Level	20dBuV ~ 120dBuV
Precision	+1.5dB
Channel scan	150
Power supply
Battery	7.2V/1500mAH rechargeable battery
AC Supply:	AC 90V-220V 50Hz-60Hz
Working time	6h
Charging time	3h

Signal Lever Meters correlation table
Model No	Constellation	Main Parameter
SNP-S110/S110D	No	Double channel, A/V, C/N, Average Power, Trunk line Voltage, Channel Power
SNP-S200/200D	No	MER, BER, Tilt, A/V, C/N, Average Power, Trunk line Voltage, Channel Power
SNP-S1127/S1127DQ	No	Spectrum, MER, BER, Tilt, Channel Power, A/V, C/N, Average Power, Trunk line Voltage
SNP-S1130/S1130DQ	Yes	Advanced spectrum, Full automatic scanning, MER, BER, Tilt, V/A, C/N, Average Power, Channel Power, Trunk line Voltage, Threshold, Alarms
