Чугунная грунтовая труба Cispi301 без втулки/ASTM A888 чугунная канализационная

Чугунная грунтовая труба Cispi301 без втулки/ASTM A888 чугунная канализационная

Категория товара: Iron Pipes >>>
Поставщик (Оптовый магазин): Chongqing,Xinlurun,Pipe,Industry,Co.,Ltd.

Цена:537,00 $ - 550,00 $

Стоимость в USD:Узнать цену

Количество:

Купить

В избранное

Описание и отзывы

Характеристики

* Sound insulation

Due to the inner sheet of graphite structure of gray cast iron, the cast iron drainage pipe can absorb the
vibration and noise generated by water flow.

The wall thickness is thicker than UPVC, and the pipes are connected with seal rubber rings, the cast iron pipe gains an good effect against noise.

* High strength and density, durable

(a. Maximum Brinell Hardness 260HB

(b.Minimum Tensile Strength 200MPa

(c.Minimum Ring Crush Strength 350MPa

(d. Minimal maintenance costs

* Anti-corrosion
Inside epoxy painting with thickness above 120 micron, outside paint ( Epoxy resin paint, epoxy coal asphalt, epoxy powder etc.) in color red with thickness above 40 micron.

* Easy to install&maintain
Flat straight pipeline, good convenience of installation. It has a reinforced seal: EPDM clamps and cuffs according to the EN681 standard. With these two parts, it is easy to set the desired rotation angles to the system.

Nominal Diameter(DN):	DN50-DN300
Sizes:	40mm-300mm
Main Material：	Cast Iron
Length:	3000mm
Wall Thickness：	3.0-7.0mm
Standard：	EN545 /BS EN877/ISO 6594/ISO2531
Application：	Drainage water system
Shape：	Round
Hardness：	230HB
Pull Strength：	>200MPa
Yield (≥ MPa):	≥350Mpa
Surface treatment:	Epoxy coating
Paint:	Red/Black/Yellow
Packing:	In bulk/Pallet

The connection of flexible cast iron pipes insists of three types: A,B and W. In general, B and W are more commonly utilized.

Size (mm)	Innerdia (mm） B	Outterdia(mm) J	Wall thickness (mm) T	Length(mm) L	Unit weight (kg)	Laying Length(m)
50	50	58	3.5	3000±20	13	180
(2”)	50	61	4.3	3000±10	16.5	180
75	75	83	3.5	3000±20	18.9	123
(3”)	75	86	4.4	3000±10	24.4	123
100	100	110	3.5	3000±20	25.2	86
(4”)	100	110	4.8	3000±10	34.6	86
125	125	135	4.0	3000±20	35.4	70
(5”)	125	137	4.8	3000±10	43.1	70
150	150	160	4.0	3000±20	42.2	59
(6”)	150	162	4.8	3000±10	51.2	59
200	200	210	5.0	3000±20	69.3	37
(8”)	200	214	5.8	3000±10	81.9	37
250	250	274	5.5	3000±20	99.8	26.4
(10”)	250	268	6.4	3000±10	113.6	26.4
300	300	326	6.0	3000±20	129.7	20.3
(12”)	300	318	7.0	3000±10	148	20.3

XINLURUN cast iron pipes fabricated by centrifugal technology STRICTLY MEET THE FOLLOW STANDARDS
Material	Pull Strength(Mpa)	Yield (≥ MPa):
No.150 cast iron implemented to ISO185	Flat straight pipe&fittings: ≥150Mpa	Average（3 times testing）：≥350Mpa
phosphorus≤0.6%	W-Type flat straight pipe：≥200Mpa	Every single test：≥300Mpa
Sulfur≤0.1%	Pipe fittings：≥150Mpa	/
Standard：EN545 /BS EN877/ISO 6594/ISO2531	Standard：BS EN877	Standard：ISO2531/EN545

Where this flexible cast iron can be used?

Construction,machine structure pipe, Agriculture equipment pipe, Water and gas pipe, Greenhouse pipe, Scaffolding pipe, Building material tube, Furniture tube, Low pressure fluid tube, Oil pipe, etc.

Chongqing Xinlurun Pipe Industry Co.,Ltd. has committed to being the premier supplier of various of quality iron and steel pipes for drinking water and drainage. With years of good long-term cooperation with state-owned iron&steel mills , our own warehouse equips a large number of stocks to ensure that we can supply customers with various of pipe choices. It operates more than 100 varieties, with an annual sales volume of 200,000 tons, and has more than 5,000 tons of spot inventory all year round.

One of our main associate factory is located in Shanxi province, it covers an area of 80,000 square meters with own advanced production equipment, laboratory independent R & D, and innovation department. It has been specializing in ductile iron pipe, SML cast iron pipe, welded pipe, seamless steel pipe,galvanized steel pipe, spiral steel pipe, stainless steel pipe, aluminum pipe, copper pipe and other various of metal material pipes and pipe fittings with an annual output of 30,0000 tons. Our associated factory has gotten CE, TUV, ISO9001, ISO2531,BIS,GOST-TR and UL certificates for different varieties of products.

Xinlurun team is trained to identify chemical and mechanical properties of each pipe we sell. We create a partnership with our customers to provide them with quality, accurate products and service. With years of experiences in pipe industry, our professional solutions in industrial drainage and civil use water projects have obtained good reputation among our customers.

Q1. Are you trading company or manufacturer?
A:We are a manufacturer with own branch company and sales department, you will get a factory-direct price from us if you buy from us.

Q2. How Can I order?
A:Please contact our sales representatives, they are able to communicate in English and will provide the most suitable purchase solutions for you.

Q3. How does your factory do regarding quality control?
A:Quality is priority. Our people always attach great importance to quality control from the production beginning to the end. We have well-trained and professional workers and strict QC system in each production link, and each product has to be 100% inspected before shipment.

Q4. What are the terms of payments?
A:We accept T/T、Western Union、LC、Paypal etc.

Q5. What's your delivery time?
A:In general, the items which are in stock will be shipped out within 3 working days, for customized products and huge order, the delivery time will be based on our negotiation. Please be assured we'll make the delivery as soon as possible with the guaranteed quality.
