Products Description
Product Introduction
1. The tank body is about 20 cubic meters
2. The side lights are charged, and two red marker lights are standard above the tail of the tank.
3. Standard front spray duckbill, standard rear flush, users can adjust the hedging position according to their own needs
4. Large platform with pattern (enhanced bearing capacity), and customized bolt buckle for the rear cover of the barrel
5. front spray, back, back sprinkling, side spray, greening anti-aircraft gun switch ball valve are used for the project 50 large diameter ball valve
6. New bearing water cannon, more durable
7. Equipped with 60-90 type high-power sprinkler pump
8. Anti-corrosion flange gasket
9, aluminum after sprinkling, not easy to explode
10. Automatic welding of tank body (Lincoln welding machine and power supply in the United States), automatic welding of jigsaw plate, circumferential seam welding of head, no porosity and beautiful welding seam
11. The side guard net and the rear bumper are all bolted, which is convenient for disassembly and maintenance
12. Plastic fenders, instead of iron fenders, are lighter and bolted for easy disassembly
13. The front and rear main pipe joints are 6-hole round flanges, which are not easy to pad
14. All small pipes shall be installed on the top, and the tank body shall be washed and sprayed with antirust paint. After assembly, the adhesion is strong and it is not easy to rust and fade.
2. The side lights are charged, and two red marker lights are standard above the tail of the tank.
3. Standard front spray duckbill, standard rear flush, users can adjust the hedging position according to their own needs
4. Large platform with pattern (enhanced bearing capacity), and customized bolt buckle for the rear cover of the barrel
5. front spray, back, back sprinkling, side spray, greening anti-aircraft gun switch ball valve are used for the project 50 large diameter ball valve
6. New bearing water cannon, more durable
7. Equipped with 60-90 type high-power sprinkler pump
8. Anti-corrosion flange gasket
9, aluminum after sprinkling, not easy to explode
10. Automatic welding of tank body (Lincoln welding machine and power supply in the United States), automatic welding of jigsaw plate, circumferential seam welding of head, no porosity and beautiful welding seam
11. The side guard net and the rear bumper are all bolted, which is convenient for disassembly and maintenance
12. Plastic fenders, instead of iron fenders, are lighter and bolted for easy disassembly
13. The front and rear main pipe joints are 6-hole round flanges, which are not easy to pad
14. All small pipes shall be installed on the top, and the tank body shall be washed and sprayed with antirust paint. After assembly, the adhesion is strong and it is not easy to rust and fade.
Specification
Chassis type | Dongfeng Huashen |
Engine horsepower/power | Kang machine 230 horsepower/169KW |
Kang machine 260 horsepower/191KW | |
Yuchai 245 horsepower/180KW | |
Yuchai 270 horsepower/199KW | |
Engine displacement | 6200 mL/6234mL |
Gearbox | Faster 8 |
Tire specifications | 11.00R20 Steel Wire Tire |
Wheelbase | 4350+1350mm |
Total mass | 25000KG |
curb weight | 10305KG |
Rated load mass | 14500/14565KG |
Vehicle size (L×W×H) | 10250 × 2500 × 3300mm |
Tank volume | 20 square |
Type of fuel | Diesel |
Emission standards | Euro 6 |
Water pump model | 60/90 |
Tank material | Q235 carbon steel |
Color | Customizable colors and logos |
Company Profile
Packing & Delivery
FAQ
Q: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
