Physical properties | rating | Units | Test methodology |
specific gravity | |||
-- | 1.04 | g/cm³ | ASTM D792 |
23°C | 1.04 | g/cm³ | ISO 1183 |
Melting rate (melt flow rate) (200°C/5.0 kg). | 5.5 | g/10 min | ASTM D1238, ISO 1133 |
Mechanical properties | rating | Units | Test methodology |
tensile strength | |||
23°C | 22.6 | MPa | ASTM D638 |
23°C | 23 | MPa | ISO 527-2 |
Elongation (fracture, 23°C). | 40 | % | ASTM D638, ISO 527-2 |
Flexural modulus (23°C). | 2260 | MPa | ASTM D790, ISO 178 |
Bending strength (23°C). | 43 | MPa | ASTM D790, ISO 178 |
Impact performance | rating | Units | Test methodology |
Unnotched cantilever impact (23°C, 6.35 mm). | 110 | J/m | ISO 180, ASTM D256 |
Thermal performance | rating | Units | Test methodology |
Heat deflection temperature under load 1 (1.8 MPa, annealed, 3.18 mm). | 90 | °C | ASTM D648, ISO 75-2/A |
Vicat softening temperature | 97 | °C | ASTM D1525, ISO 306/B |
flammability | rating | Test methodology | |
UL flame retardant rating (1.50 mm, Natural Color). | HB | UL 94 | |
Supplemental Information | rating | Units | |
Residual monomers | ppm | ||
injection | rating | Units | |
Drying temperature | 75 | °C | |
Drying time | 1.0 to 2.0 | hr | |
Hopper temperature | 40 | °C | |
Barrel rear temperature | 190 | °C | |
Temperature in the middle of the barrel | 200 | °C | |
The temperature of the front of the barrel | 210 | °C | |
Nozzle temperature | 205 | °C | |
Processing (melt) temperature | 180 to 220 | °C | |
Mold temperature | 20.0 to 70.0 | °C | |
Injection speed | medium |
