Overview
Chinese Top Brand 100hp Bulldozers Dozer Bulldozer DH10K for Hot Selling
Power System
Strong power, high efficiency and energy-saving, and low maintenance cost. The rated power, featuring high torque reserve coefficient. The improved air filter and intake and exhaust system guarantee up to 99% filtration accuracy to effectively prolong the engine life.
Working adaptability
Brand’s stable and reliable chassis system is applicable to diversified severe working conditions. The product features long ground length, high ground clearance, stable driving, and good trafficability.
Drive system
The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency. brand’s self-made drive system features stable.
Strong power, high efficiency and energy-saving, and low maintenance cost. The rated power, featuring high torque reserve coefficient. The improved air filter and intake and exhaust system guarantee up to 99% filtration accuracy to effectively prolong the engine life.
Working adaptability
Brand’s stable and reliable chassis system is applicable to diversified severe working conditions. The product features long ground length, high ground clearance, stable driving, and good trafficability.
Drive system
The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency. brand’s self-made drive system features stable.
Product Description
Specification
Performance parameters | Net power/rated speed(KW/h) | 127/170@ 2000 |
Operating weight(kg) | 10000 | |
Ground pressure(kpa) | 64 | |
Ground length(mm) | 2675 | |
Overall dimensions | Overall length(mm) | 5250 |
Overall width(mm) | 3420 | |
Overall height(mm) | 3080 | |
Travelling performance km/h | Forward | 0~10 |
Reverse | 0~10 | |
Gradeability(degree) | 30 | |
Ground clearance(mm) | 370 | |
Working device | Blade type | Angle blade |
Blade width(mm) | 3400 | |
Blade height(mm) | 1200 | |
Working capacity(m3) | 4.4 | |
Maximum lifting height(mm) | 1010 | |
Maximum digging depth(mm) | 520 | |
Ripper type | Three- tooth ripper | |
Maximum inclination(mm) | 460 | |
Digging depth(mm) | 475 | |
Lifting height(mm) | 570 | |
Chassis system | Track gauge(mm) | 1880 |
Width of track shoes(mm) | 510 | |
Track pitch(mm) | 213 | |
Number of track rollers(one- sided) | 7 | |
Tank capacity | Fuel tank(L) | 320 |
Working hydraulic oil tank(L) | 85 | |
Travelling hydraulic oil tank(L) | 65 |
