Company Information
Shanghai Hong An Marine Co.Ltd. Is a company manufacturing yacht made of fiber-glass and other materials.With our yacht we bring you credible quality and fashion outlook. Our yacht could be used for multiple purpose, such as military, marine traffic management,tourist sight-seeing, flood rescue and marine products industry.We also sell all kinds of inboard and outboard engines(gasoline or diesel),imported yachts as well as yacht parts, marine oils and marine product.
Product Description
Boat Specifications:
Length Overall: 14.5 m
Beam Overall: 3.3 m
Draft: 1.40 m
Hull Weight: 2780 Kg
Hull Material: Fiberglass
Total Weight: 7550 Kg
Fresh Water Tank: 50L
Fuel Tank: 500 L
Capacity: 40persons + 2crews
Fuel Consumption at full throttle: 140L/h (twin engines)
| Nr. | Name of Item | Description | QTY |
| A | Main and Subsidiary Material | ||
| 1 | Fiberglass | 3500kg | |
| 2 | Marine Gelcoat | 350kg | |
| 3 | Wooden Material | ||
| 4 | Assitance Material | 1set | |
| 5 | Prescription | 1set | |
| 6 | Sandiwich plate | 1set | |
| 7 | PVC plate | 10pcs | |
| 8 | |||
| B | Marine Equipements | ||
| 1 | Bilge Bump | rule 1800 with float switch | 1set |
| 2 | Twin Cushioned Seats | General | 10sets |
| 3 | Twin Cushioned Seats w/ fold seats | General | 10sets |
| 4 | Single Seat | General | 1pc |
| 5 | Wooden Bench | Made by factory | 2pcs |
| 6 | Pilot Seat | Foreign Brand | 1pc |
| C | Metal Hardware | ||
| 1 | Anchor with Rope | 316 stainless steel | 1set |
| 2 | Heavy Duty D-Type Rubber Fender | "100mm*100mm" | 1set |
| 3 | Mooring Cleat | 2 for each side, 1 on the bow | 1set |
| 4 | Fender | 316 stainless steel | 1set |
| 5 | Handrail | 316 stainless steel | 1set |
| 6 | Window Shield | 4 nos windows at each side of the vessel | 1set |
| 7 | Windows | 1set | |
| 8 | Lightning Rod | 1set | |
| 9 | Horn | 1pc | |
| 10 | Washiong Room | Toilet, Basin and Small Mirror | 1set |
| D | Electric Sytem | ||
| 1 | Marine Cable | 1set | |
| 2 | Lighting | six for compartment | 6pcs |
| one for washing room | 1pc | ||
| two for engine room | 2pcs | ||
| 3 | General Switch | 1set | |
| 4 | Air Cooling Diesel | 1set | |
| 5 | Air Conditionor | 1et | |
| 6 | DVD Player with Mornitor and Speakers | 1set | |
| 7 | Naturel ventilation inlets and outlets at port and starboards side of the hull | 2sets | |
| 8 | Electric Wiper | 1set | |
| 9 | Compass | A54 | 1pc |
| 10 | Romote control search light | JABASCO 135SL | 1pc |
| 11 | S.S mast for navigation system | Stainless steel | 1pc |
| 12 | Batteries | for Cummins diesel engines | 2pcs |
| 13 | Fuel Tank | 500L | 1set |
| 14 | Fresh water Tank | 200L | 1set |
| 15 | polypropylene Rope | 15M*22mm | 1set |
| E | Life Saving and Fire Fighting equipement | ||
| 1 | Bouys | 2pcs | |
| 2 | Life Jackets | with light and whistles | 55pcs |
| 3 | Fire Pail | 2pcs | |
| 4 | FireExtinguisher | 6KG | 4pcs |
