SMC Type CJP Series Single Acting Pin Cylinder

Features:

1.CJPB series Pneumatic cylinder(Single acting).

2.Equivalent to SMC CJPB series  Pneumatic cylinder, with the same appearance.

3.Bore size(mm): 6, 10, 15.

4.Single acting, Single rod, Spring return

5.Panel mounting or plug mounting is potional.



How to Order:


Specification:

Bore size (mm)61015
FluidAir
ActionSingle acting, Single rod, Spring return.
Minimum operating pressure0.2 MPa0.15 MPa
Maximum operating pressure0.7 MPa
Proof pressure1.05 MPa
Ambient and fluid temperature -20 to 80°C (No freezing)
CushionNone
LubricationNon-lube
Piston rod dia.3 mm5 mm6 mm
Rod end thread With Thread(Male)M3x0.5M4x0.7M5x0.8
Without thread-
Port SizeM5x0.8



Main Material:



No.DescriptionMaterialNote
1.Cylinder barrelBrassElectroless nickel plated
2.Piston rodStainless steel-
3.Rod coverBrassElectroless nickel plated
4.PistonStainless steel-
5.SealNBR-



Dimensions and Sizes:
