OVERVIEW

WiFi Vending Machine brings a brand-new vending business into public market. It provides visitors an immediate WiFi Internet service.

Everyone has a smartphone, but not everywhere have WiFi. WiFi Vending Machine can fill this huge gap between WiFi needs and WiFi Coverage.

The machine is plug-&-play and easy to install. And the best part is all investment can be returned in 3 months.

COMPARISON

Send Inquiry for Special Discounts

FUNCTIONS

• No inquiry, no username, and no password is required; just tap the phone, insert coins, and get WiFi.
• Provide WiFi signal coverage (100m for outdoor / 30m for indoor) and support 50 concurrent users.
• No need for supervision. Self-service working method to save labor cost.
• Provide user-friendly pop-up instruction page to tell end users how to get WiFi service.
• Excellent coin-learning ability to recognize your local coins and discriminate fake coins.
• Offer cloud-based NMS (Network Management System) to monitor all online machines remotely.
• Support account roaming between different machines to help end users enjoy your WiFi service in multiple sites (optional).
• Professional coin passage design to prevent coin stolen or fraud.

Send Inquiry to Get More Product Information

FEATURES

Send Inquiry to Get Complete User Instructions

BENEFITS

• Venue owners can get extra revenue by providing WiFi service and attract more visitors which is good for his original business;
• Venue owners can display advertisements for their products on the login page for better promotion, or show ads for other shops to get income;
• Travelers can get quick and cheap Internet access without paying expensive charge for data roaming or new SIM card;
• Visitors can check/send email, browse websites, and use high-speed VPN to connect enterprise network from any WiFi-enabled laptop, PDA, smart mobile phone, or handheld device.
• No WiFi squatter because no username and password is required.

APPLICATIONS

• Long-stay place: dormitories, apartments, hotels, hospitals;
• Crowed public place: stations, food centers, restaurants, coffee shops, pubs, lounge bars, Karaoke bars, beauty salons, chain shops, lobby of banks/hotels;
• Sports area and recreation centers: bowling, billiards;
• Tourism place: international airports, beaches, parks, swimming pools, exhibition and convention sites.

CASE STUDY

This is a real case of WiFi Vending Machine installed in Thailand. The owner needs to sell WiFi in an apartment with 3 floors and 90 residents. He adopts the following solution:

• 1x WiFi Vending Machine installed at the entrance on 1st floor
• 8x access points installed at the ceiling of corridor on 2nd to 4th floor
• WiFi service price is set as: 10 Baht = 60 minutes, 15 Baht = 120 minutes, 20 Baht = 1440 minutes

The daily income of this solution can reach 300 Baht and the owner can get all his investment back in the very first 3 months.

90% of visitors has contacted us to get valuable information, like:

• How to run a successful WiFi business?
• How to make the WiFi signal cover a dormitory with limited budget?
• How to run WiFi business with video service via Internet connection of low bandwidth?

Send Inquiry to Acquire Detailed Business Proposal & Case Study

DEMO VIDEO

Related Products

TECHNICAL SPECIFICATIONS

Environmental Conditions	- Temperature: 5°C to 45°C (operation) / -10°C to 60°C (storage) - Humidity: 10% ~ 85% non-condensing
Power Requirement	- External adaptor (input: 100~240 VAC, 50/60 Hz / output: 12VDC, 1A) - Power consumption: 6 watts
WiFi Operation Range	Radius up to 100 meters (outdoor) / 30 meters (indoor)
WiFi Frequency Range	BAND 2.412 to 2.484 GHz (and 5.150 to 5.875 GHz, optional)
Supported 4G Frequency Bands (optional)	LTE FDD: DD800/900/1800/2100/2600MHz
Supported Max. 4G Data Speed (optional)	LTE FDD: Cat4 Download: 150Mbps / Upload: 50Mbps @20M BW
Supported Device for Tapping	Any WiFi-enabled mobile phone, tablet, laptop, PSP, PDA, etc.
Networking	- IEEE 802.11 b/g/n Wireless LAN - Zero end-user configurations
Authentication	Built-in user authentication and accounting
Remote Management via NMS (optional)	- Setting of WiFi name, WiFi service price, data speed limit - Revenue records of WiFi Internet service - Supervision on running status of each hotspot router
About Coins	- Coin Acceptance: 15 different types - Usable Coins: Diameter: 16mm ~ 31mm, Thickness: 1.2mm ~ 3.2mm - Coin Box Capacity: 1 liter (optional metallic coin box: 2.7 liters)
Structural	- Housing Material: ABS plastic - WAN Interface: 1x RJ45 port, or built-in 4G USB modem (optional) - Antennas: 1x WiFi (built-in), or 1x 4G (optional, built-in USB modem) - LCD: 4-line, 128X64 pixels, backlight supported, shock resistance ≥ 4,000N - Dimensions: 250mm (L) X 193mm (W) X 360mm (H) - Weight: 3.1 kg - Packing Dimensions: 320mm (L) X 240mm (W) x 430mm (H) - Packing Weight: 3.8 kg

Frequently Bought Together

FAQ

FAQ

Q: How does the WiFi Vending Machine get Internet?

A: You need to connect the WiFi Vending Machine to a DSL/Cable/Fiber Optic modem or a router via an Ethernet cable. For the 4G version, you can also insert a 4G/LTE SIM card inside the machine to make it have backup 4G connection.

Q: Can the WiFi Vending Machine recognize my country's coins?

A: Yes, it can most coins in the world after a simple "coin-learning" operation. That means you just need to insert some coins and do some menu operation.

Q: Can I extend the WiFi signal coverage range?

A: Yes, we recommend you to connect the machine with our Access Points (AP) to extend the coverage. We can provide professional suggestion if you can provide the plan diagram of the area.

Q: Can I add my company name and logo on the WiFi Vending Machine?

A: Yes, we can provide OEM service based on batch orders.

Q: Can the WiFi Vending Machine support more than 50 concurrent users?

A: Yes, we have high-end version which can support 200, 300 or 500 concurrent users with different price.

Q: Can I set the price for WiFi service? Is it based on time duration or bytes usage?

A: Yes, you can set the price in the cloud-based NMS (Network Management System). Either time-based or data-based is supported.

Q: How long can I get my investment back if I want to do this business?

A: Usually it will take 3~6 months. It depends on the setting of WiFi service price and the number of WiFi service users at the installation site.

Q: How can I make sure that I can run this business successfully?

A: To make this business successful, there are 3 major factors:

• Ability to find and acquire the appropriate installation place (especially the place where many people stay for a long time) and to pay for acquisition reasonably.
• Facility and low cost of broadband Internet access.
• Coverage and quality of WiFi signal.

Send Inquiry to Know More FAQs

Packaging & Shipping

PACKAGING & SHIPPING

Our product will be packed in a carton after careful testing and inspection. Each package will include an AC/DC power adapter and door keys.

FAST DELIVERY

• We have strong cooperation with DHL, UPS, FedEX, EMS and TNT.
• You can also choose your own forwarder.
• Sample order will be delivered within 3 work days.
• Batch order up to 1000 units will be delivered within 30 work days.

Our Services

OUR SERVICE

• Any inquiry of our products will be replied within 1 work day.
• OEM is available for batch orders:
• Silkscreen printing on casing
• Brand Label on casing
• Package carton printing
• Product feature
• Warranty and after-sales service:
• Have a 1-year warranty and during the warranty we will provide free-of-cost technical support
• We will provide online support service via email, instant messenger, instruction document and video
