Full Automatic carbonated beverage mixer/production machine is used for producing all carbonated beverages (water, syrup, and CO2 mixing), for example lemon, coca cola, fruits juice and so on. It is the main equipment in whole beverage production line. (Especially for middle and higher standard beverage production).

1,Parameter

(1). Range of proportion on syrup and water                    1:3 1:10

(2). Volume of Carbonation                                             (CO2: H2O in volume) 2: 5

(3). Mixing precise error                                                     ≤2%

(4). Cooling water temperature in entry mouth                 0-4

(5). Cooling water pressure in entry mouth                      0.01-0.08Mpa

(6). Syrup temperature in entry mouth                              2-8

(7). Syrup pressure in entry mouth                                     0.01-0.08Mpa

(8). CO2 pressure in entry mouth                                     0.7-0.8Mpa

(9). CO2 pure %                                                               99.9%

(10). Pressure for CO2 tank and syrup tank                      0.05-0.09Mpa

(11). Working pressure of tank                                         0.2-0.5Mpa

(12). Total motor power                                                     6.3KW

2   Products Structure and Working Procedure

(1). CO2 tank, syrup tank, liquid level device, static mixing device, tank, electrical controlling system, air providing tank, and necessary producing pipe and cleaning pipe including ball valve, magnetism valve, check valve are composed this machine. (See photo 1: main structure)

(2). Main working Procedure

a. Cooling water→multi-grade pump→oxygenating CO2→volume control

b. Cooling syrup→multi-grade pump→syrup tank→volume control

(a and b → multi-grade pump→static mixing device→

c. CO2 air resource→filter and pressure reducing→ tank→filling machine
