Программное обеспечение FastCAM профессиональная версия поддержка нескольких языков для станка резки с

Product Application

FastCAM have 30-years R&D history and famous brand in the world cutting & welding industry. FastCAM software are professional in drawing, nesting and programming for Gas, Plasma, Laser and Water-jet NC cutting machine. It is easy to learn and use without PC & AutoCAD basis. FastCAM supply multilingual software, technical support and training in America, Europe, Asia Pacific and China. FastCAM promote new technology to maximize productivity, improve quality and reduce cost.

FastCAM software has four modules for CNC cutting:
FastCAM drawing module:
1)Draw: similar with CAD, to draw all kinds of parts
2)CAD compatible and Optimizer: to read in and optimize DXF/DWG files by delete, compress, extract, explode
3)Cutting functions: Kerf compensation, plasma bridge, common line cutting, corners, CAD layers, word label

FastNEST automatic nesting module:
1)Manual nesting, easy & convenient to use
2)Automatic nesting in a row or in a matrix
3)Full automatic nesting
4)Interactive nesting by auto and manual nesting
5)Common cut & continue cut to reduce pre-pierce
6)Remnant nesting for irregular remnant or parts

FastPATH automatic pathing module:
1)Programming: automatic & manual pathing include marking, path optimizer, multi-layer cutting
2)Support multiple CNC control, ESSI&EIA G/M code
3)Support Kerfs comp., pre-pierce, stitch& tag cutting

FastPLOT verification module:
1)NC Verification: automatic & manual simulation, dimension and kerf compensation verification
2)Costing: utilization, cut length, pierce & cutting cost
3)Transfer NC files to CAM/DXF/DWG files
FastCAM Support: Windows98/2000/NT/XP/vista
FastCAM Multi-languages: Chinese/ English/ German/ Spanish/Polish/Korea/Czech/Russian etc.

Composition and function

FastCAM nesting software initiative in 1976, has a long development history of nearly 30 years, considering the convenience of nesting programmers use, conform to the daily work process and the use of habits, the software always maintain the structure and use simple and clear steps, as shown in the figure below, according to the drawing - > set of material - > - > check the working process of the NC programming and use habits, FastCAM nesting software is divided into four modules, namely FastCAM drawing module, FastNEST nesting module, FastPATH programming module and FastPLOT check NC module, the function of each module can be briefly summarized as three aspects, the article introduces one by one.

Read the DXF/DWG file for CAD clearance compression

Various cutting functions under standard parts

Remaining steel nesting and management

Common side cutting and continuous cutting function

Special treatment of sealing, preperforation and small holes

Cost calculation and statistical function
