China Wholesale 8kW 9kW ZRT Tilted Single Axis Solar Tracking System 100kW
- Категория товара: Улавливателя солнечной энергии >>>
- Поставщик (Оптовый магазин): Shandong,Zhaori,New,Energy,Tech.,Co.,Ltd.Shandong,Ltd.
Поделиться:
Описание и отзывы
Характеристики
\t\t\t\t\t\t\t\t\tProduct Description \t\t\t\t\t\t\t
ZRT tilted single axis solar tracking system, it owns very simple structure, easy for installation and maintenance. It has one auto axis to track the sun in east-west direction automatically every day, with 10°-30° tilted angle in south-north direction, promote your power generation by 15%-25% comparing to fixed brackets.
\t\t\t\t\t\t\t\t\tOur Advantages \t\t\t\t\t\t\t
★ Patent technology, simplest structure, low cost.
★ Conveniently and quickly installation, no need for big machinery.
★ Less power consumption, only totally about 3kWh/set/year.
★ High strength brackets, good wind resistance performance, auto wind protection.
★ Solar panels can be adjusted to a tilt angle for snow proof purpose.
★ More stable three-points support structure.
★ No fixed coverage to sunshine or raining, no affection to plants growing.
★ Effectively reduce your solar panels washing times.
★ Less components, light single part weight, convenient transportation.
★ Intelligent control, self-correction & self-positioning, easy maintenance.
★ Mature and reliable technology, low failure rate, high tracking accuracy.
★ High efficiency, +20% - 25% more energy!
Company Profile
Shandong Zhaori New Energy Tech. Co., Ltd. locates in Weicheng Economic and Technological Development Zone of Weifang City, Shandong Province. The company registered capital comes to 8 million USD, it is a high-tech & new energy company based on independent intellectual property rights, committed to researching and producing most simple and best cost performance smart solar tracking systems, promoting power generation capacity by 15%-45%, with TUV & CE certificates and patent of invention from many countries.
Our Goal: more simple, more reliable, more efficient
Our Aim: excellent products, excellent service
Our Wish: share the solar future with you
Our Goal: more simple, more reliable, more efficient
Our Aim: excellent products, excellent service
Our Wish: share the solar future with you
\t\t\t\t\t\t\t\t\tSpecifications \t\t\t\t\t\t\t
Product name: | ZRT tilted single axis solar tracking system |
Control mode: | Time + GPS Control |
Tracking accuracy: | 0.1°-2° (Adjustable) |
Motor: | 24V gear motor |
Power consumption: | 3 kwh/set/year |
Output torque: | 5000NM |
Azimuth angle tracking range: | ±49° |
Brackets material: | Hot-dipped galvanized steel, Zinc layer thickness≥65μm |
Max. wind resistance: | 24m/s in running state, 40m/s in wind protect state |
System guarantee: | 3 years |
Working temperature: | -40℃ - +75℃ |
Weight: | 150kgs - 300kgs |
Mount solar panels: | 10 - 50 solar panels |
Total power: | 2.5kW-15.0kW |
