Стандартный треугольный V-образный ремень

Описание и отзывы

Характеристики

Standard triangle V-belt

Standard triangle belt A,B,C,D,Z *  Anti - oil, anti - static *  Operating temperature: -18℃ to +70℃ *  Maximum linear speed: 30 m/s

*  top width: 13mm     *  Minimum rim diameter: 75mm *  Height: 8mm       * Li= La-50mm *  Angle: 40°          * Li= Lp-36mm

*  top width: 17mm     *  Minimum rim diameter: 125mm *  Height: 11mm       * Li= La-69mm *  Angle: 40°            * Li= Lp-43mm

*  top width: 22mm     *  Minimum rim diameter: 120mm *  Height: 14mm       * Li= La-88mm *  Angle: 40°            * Li= Lp-56mm

*  top width: 32mm     *  Minimum rim diameter: 355mm *  Height: 19mm       * Li= La-119mm *  Angle: 40°            * Li= Lp-79mm

*  top width: 10mm     *  Minimum rim diameter: 50mm *  Height: 6mm       * Li= La-38mm *  Angle: 40°          * Li= Lp-22mm

type

top width

Height

Angle

The length measurement

outer perimeter

Z

10

6

40º

Li

Li+38mm

A

13

8

40º

Li

Li+50mm

B

17

11

40º

Li

Li+69mm

C

22

14

40º

Li

Li+88mm

D

32

20

40º

Li

Li+119mm

specific size

SPZ

10

8

40º

Lp

Lp+13mm

SPA

13

10

40º

Lp

Lp+18mm

SPB

17

13

40º

Lp

Lp+20mm

SPC

22

18

40º

Lp

Lp+30mm

specific size

3V

9.7

8

40º

La

5V

16

14

40º

La

8V

25

23

40º

La

specific size

Guizhou GZG Transmisison Co., Limited locates in Duyun Guizhou. We have been engaging in manufacturing and supplying mechanical transmission parts, which are highly demanded and widely used in diverse industries across the world, since our company established in 2017.

We aim to provide our customers with a complete line of of good quality products available in various materials and sizes at competitive pricing. Meanwhile, we offer the best service to make our clients satisfied no matter the order is small or big.

We are also one of the reliable and trustworthy vendors in European, American, African, Asian markets etc. Many OEMs trust the GZG brand to run their equipment due to its superior strength, durability, performance and long functioning life.

Our main products are all kinds of standard and non-standard roller chain,  sprocket,V-belt,pulley,coupling,and other power transmission products.

· High quality products at competitive pricing

· Wide variety of products available in various materials and sizes

· Our products are manufactured in an ISO9001:2008 certified factory

· Great customer service that's here to answer all of your questions

· Largest online selection of power transmission products

· Easy online shopping and ordering available 24/7 - 365 days a year

· High quality made to order products

           FAQ

Q1. Can I get a sample to check quality before the order ?

As usual, we don’t advise to send sample because the cost would be high. But it is okay if there is stock for standard products and also customers can pay for freight.

Q2. How long is it about your delivery time ?
It depends on customers’ purchasing quantity and our present production situation.

Q3. What is your minimum order quantity ?
Our MOQ is 100 pieces; And standard V-Belt in stock, about 20 pieces is available.

Q4. What kind of certificate does your factory have ?
We have passed ISO quality management system certification.

Q5. Does your factory have test facilities ?
We have own lab with different testing facilities, such as strength tensile, working load.

   Read Before Inquiry

1. For standard V-Belt, what is the Item No. (ANSI/ISO/DIN) you are looking for ?
2. For non-standard V-Belt, do you have drawings for them ?
3. What is the application condition of the chain you need ?

4. What material do you require?

5. How many quantity do you purchase for this order and for a year ?

6. Do you have special requirements for the marking and packaging?
