You are here:Home >>Precision bar>>Precision Iron Alloy Invar 36 Bar
Product Description
Precision alloy series: 1J33,3J01,3J9,4J29,4J32.4J33,Invar36,4J45.FeNi50.
| Property:magnetic property, high magnetic conductibility,high resisitance, | |||||||||||
| High hardness,high saturation induction,ect. | |||||||||||
| Function:memory element,compensating element,inductance element for | |||||||||||
| Transformer, magnetic amplifier.isolating flake,magentic head for | |||||||||||
| recorder, Movie machine, Checking attendance machine.iron core for Transformer,choke,pulse transformer,relay,and magnetic amplifier. |
Main applications: Magnetic shunt compensatory element In the electromagnetic loop and the permanent magnetic loop.
Invar36 Specification
| Bar:10mm-250mm | ||||||||||
| Cold rolling strip: 0.1mm-3.0mm×≤420mm | ||||||||||
| hot forged material:diamerter 5.5mm-250mm,square:40mm-240mm×40mm-240mm | ||||||||||
| cold drawing wire:diameter 0.1mm--18mm | ||||||||||
| hot rolling plate: 3.0mm-60.0mm×100mm-610mm | ||||||||||
| Seamless tube: φ6mm~φ219mm×0.5mm~18mm | ||||||||||
| Welded tube: φ1mm~φ120mm×0.1mm~10mm |
Invar36 Chemical Composition
| Item | Chemical Composition (%) | |||||||||
| Brand | C | S | P | Mn | Si | Ni | Cr | Al | Fe | |
| 1J30 | ≤0.04 | ≤0.020 | ≤0.020 | ≤0.40 | ≤0.30 | 29.5-30.5 | bal | |||
| 1J31 | ≤0.04 | ≤0.020 | ≤0.020 | ≤0.40 | ≤0.30 | 30.5-31.5 | bal | |||
| 1J32 | ≤0.04 | ≤0.020 | ≤0.020 | ≤0.40 | ≤0.30 | 31.5-32.5 | bal | |||
| 1J33 | ≤0.05 | ≤0.020 | ≤0.020 | 0.30- | 0.30- | 32.8-33.8 | 1.0-2.0 | |||
| 0.6 | 0.6 | bal | ||||||||
| 1J38 | ≤0.05 | ≤0.020 | ≤0.020 | 0.30- | 0.15 | 37.5-38.5 | 12.5-13.5 | bal | ||
| 0.6 | 0.3 | |||||||||
