Fiber optical transceiver 1 optical 8 electric switch with Reverse Power Supply
Product Description
PoE switch is a Power over Ethernet Switch, fully satisfied equipment’s frequently need to be powered in physical locations where mains power is not available or difficult to deliver. With data and power over Ethernet, the PoE switch is able to reduce cable installation and eliminate the need for electrical outlets on the wall, ceiling or any unreachable place. Energy saving is the key feature of the use of PoE in the deployment. PoE switch provides a compact, affordable, safe and reliable power solution for small to medium enterprises.
Features
- Conforms to IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE802.3af, IEEE802.3at
- Provides 9 10/100/ Base-TX ports
- Provides 8 PoE injector and build in Industrial power
- High back-plane bandwidth 1.8Gbps
- IEEE802.3x Flow control
- Surge protection for power port and data ports
- EMI standards complies with FCC, CE class B
- Built-in power supply and noiseless fan.
Specification
| Hardware | |
| Interface | 9 10/100M Base-TX ports , Auto-Negotiation, Auto MDI/MDIX |
| LED Indicator | PWR, 1-8 10/100M POE, 1-9 LINK/ACT LED |
| Power Supply | 100-240V AC/50-60Hz |
| POE Power | 15.4W per port, IEEE802.3af |
| Pin assignment | V+ (RJ45 Pin 4, 5), V- (RJ45 Pin 7, 8) / V- (RJ45 pin1,2) V+ (RJ45pin3,6) |
| Dimensions (L×W×H) | 330mm×200mm×44mm |
| Switching Features | |
| Standard | IEEE 802.3 10Base-T, IEEE802.3u 100Base-TX Fast Ethernet IEEE802.3x Flow Control, IEEE802.3 af/at Power Over Ethernet |
| Access Method | CSMA/CD |
| Transmission Method | Store and Forward |
| Switch Architecture | Non-blocking |
| Data Transmission Capacity | 10/100Mbps (Half-duplex) 20/200Mbps (Full-duplex) |
| MAC Address Table | 1K |
| Others poe | |
| Certification | FCC,CE,RoHS |
| Environment | Operating Temperature: 0°C-40°C Storage Temperature: -20°C-70°C Operating Humidity: 5%-90% non-condensing Storage Humidity:5%-90% non-condensing |
| Package | 1* POE Switch(built-in power supply) 1* User's Mannual 1* Warranty Card |
Products Overview:
Hot sale
Hot Sale
Company Information
Shenzhen Wangtong Industry Company Limited is a high-tech private-run enterprise specialized in research development ,manufacturing customized FWDM/CWDM/DWDM, EDFA, optical receiver, optical transmitter. Mainly manufacturer of Optical Fiber Transmission, Data Communication and Network Access Equipments. Including fiber optical splitters, fiber optic adapter, fiber optic cable, patch cord, optical coupler, wavelength division multiplexer, optical attenuator, fiber optic splice enclosure, fiber optic terminal box, distribution box ,fiber optic toolkits etc. Those products have been widely applied in more than 30 industries like telecom, broadcast&television, traffic safety protection, computer etc.
