Product Description
1. Application
The packer features a non-welded design that provides a strong and effective seal in the vertical, deviated and horizontal wells.
They are available for virtually all drilling, completion, and workover requirements  and etc.
2. Features
- Set by hydraulic pressure
- Release by straight pull / rotate
- Multiple rubber sleeve to ensure sealing stability
- Pressure rating up to 10000 PSI (68.9MPa); Temperature application up 150℃ （302℉）
- Good performance
3. Technical data
See data sheet as below
Casing Size
/inch
Casing WT.
OD/mm
ID/mm
Overall Length/mm
Setting Force/
kN
Connecting Thread
5″
18#-13#
100
45
1330




20-30
27/8UPTBG
5 1/2″
23#-17#
114
57
1350
5 1/2″
23#-17#
115
62
1370
7″
32#-23#
148
76
1480
31/2UPTBG
7″
29#-23#
150
76
1600
7″
29#-23#
150
60
1600
