Cylinddrical grinding machine M1320 cylinddrical grinder machine price
Products Description
Details Display
Specifications | Units | M1320 | MW1320 | ||
Max. length ground(O.D) | mm | 500/750 | 500/750 | ||
Center height | mm | 125 | 135 | ||
Dia. Ground(O.D) | mm | 8-200 | 8-200 | ||
Max. weight of work piece kg | kg | 50 | 100 | ||
Center taper | MT | 3 | 4 | ||
Spindle speed | r/min | 50HZ:25~260 | 50HZ:25~380 Stepless | ||
Wheel size (ODxWxID) | mm | 400x40x203 | 500*50*203 | ||
Peripheral velocity | m/s | 35 | 35 | ||
Swiveling angle | r/min | 1335 | 1335 | ||
Wheel head rapid travel | mm | 50 | 50 | ||
Max. travel | mm | 205 | 205 | ||
Hand feed per rev | mm/rev | 1 | rough:2 precision：0.5 | ||
Hand feed per gra | mm/gra | 0.00125 | rough：0.01 precision：0.0025 | ||
Wheel size (ODxWxID) | mm | 500x50x203 | 500*50*203 | ||
Peripheral velocity | m/s | 35 | 35 | ||
Hand feed per | mm/rev | 6 | 6 | ||
Max. swiveling angle of table | Cockwise | ° | 5° ( 500 ) 3° ( 750 ) | 3° | |
Anticlockwise | ° | 9° | 9° (500) 8° (500) | ||
Longitudinal speed range of table | m/min | 0.1-4 | 0.1-4 | ||
Center taper | MT | 3 | 4 | ||
Quill travel mm | mm | 25 | 30 | ||
Wheelhead motor power | kw | 3 | 5.5 | ||
Workhead motor power | kw | 0.25/0.37 | 1.1 | ||
Machine weight | kg | 2400 ( 500 ) 2900 ( 750 ) | 3000(500) 3100(750) | ||
Overall dimension(L * W * H) | mm | 1920x1450x2050(500) | 2350*2030*2050(500) | ||
2130x1450x205 0(750) | 2750*2030*2050(750) | ||||
Recommend Products
Company Profile
FAQ
1. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.
2.What CNC system do you use?
A: FANUC, SIEMENS, MISTSUBISHI, LNC,SYNETC,GSK,etc. It depends on your choice.
3.When is the delivery time?
A: Conventional Machines,We will delivery then within 30-45 working days after received your deposit,if some special machines will
be some longer.we will give you the answer accordingly.
4. What is the package of the machines?
A: The machines standard packed by iron pallets with plastic films.
5.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .
6. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.
8. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
A: MOQ is one set, and warranty is one year.
2.What CNC system do you use?
A: FANUC, SIEMENS, MISTSUBISHI, LNC,SYNETC,GSK,etc. It depends on your choice.
3.When is the delivery time?
A: Conventional Machines,We will delivery then within 30-45 working days after received your deposit,if some special machines will
be some longer.we will give you the answer accordingly.
4. What is the package of the machines?
A: The machines standard packed by iron pallets with plastic films.
5.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .
6. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.
8. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
