Лидер продаж, линия прорезьбовых катушек из листового металла
US $40000-$60000
Спиральная высокоточная продольная машина дешевая алюминиевая 0,5-3x2000 мм высококлассная машина для резки листов 0,5-3 мм 1 - 30
- Категория товара: Бобинорезательный станок >>>
- Поставщик (Оптовый магазин): Wuxi,Hai,Roll,Fone,Science,And,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Company Profile
Products Description
The slitting machine is also called vertical slitting line which are used to slit cold rolled steel coil,hot rolled steel coil,galvanized steel coil,silicone steel coil,stainless steel coil,aluminum coils etc into different width according to the user’s production demands and cut as well
The smaller metal strips are recoiled at the end of the slitting machine by which these smaller strips are used necessarily for the next process usage in the professional field of making transformers,motors making industry,tube/pipe welding mill industry,Cold roll forming industry, ceiling drywall industry and other high-precison equipment making and metal strips making industries.
According to the material slitting thickness there are thin plate or board slitting machine,media-thickness plate or board slitting machine and thick plate or board slitting machine.
According to the metal materials there are copper strips slitting machine,stainless steel slitting machine,cold or hot rolled plate slitting machine,silicone steel slitting machine.
The smaller metal strips are recoiled at the end of the slitting machine by which these smaller strips are used necessarily for the next process usage in the professional field of making transformers,motors making industry,tube/pipe welding mill industry,Cold roll forming industry, ceiling drywall industry and other high-precison equipment making and metal strips making industries.
According to the material slitting thickness there are thin plate or board slitting machine,media-thickness plate or board slitting machine and thick plate or board slitting machine.
According to the metal materials there are copper strips slitting machine,stainless steel slitting machine,cold or hot rolled plate slitting machine,silicone steel slitting machine.
Product Paramenters
Input coil parameter | ||||
1. | Material | CR,Color Steel,PPGI | ||
2. | Thickness | 0.5～3.0mm | ||
3. | Width | 500～1800mm | ||
4. | Mechanical character | TS≤450MP YS≤260MP | ||
5. | Coil ID | Ø508mm | ||
6. | Coil OD | Ø800mm ～ Ø1800mm | ||
7. | Weight | 15t | ||
Finished product parameter: | ||||
1. | Thickness | Maintain original thickness | ||
2. | Coil ID | Ø508mm | ||
3. | Coil OD | ≤Ø1800mm | ||
4. | Weight | MAX：15t | ||
5. | Slitting strips (excluding two scrap strips) | According to purchaser’s requirement | ||
6. | Width accuracy | Width＞300mm, ±0.1mm | ||
7. | Straightness (bending) | If the two side strips are within 100mm of the mother material, considering as the common production process | ||
8. | Burr | Thickness ≤1.0mm,burr≤0.03mm （Sharp blade, reasonable gap） Thickness ＞ 1.0mm,burr ≤3% of material （ Sharp blade, reasonable gap） | ||
9. | Min strip width | 35mm | ||
10. | Scrape width range | 2～25mm（Not less than 1.5 times the thickness） | ||
11. | Max scrape weight | ≤200kg/coil | ||
12. | Misalignment accuracy | ±0.5mm | ||
13. | Tower shape tolerance | ±3.5mm（exclude Inner layer 5~10 laps） | ||
14. | Surface | No processing defects | ||
Machine parameters | ||||
1. | Guiding speed | ～10m/min（adjustable） | ||
2. | Line speed | 0～150m/min（adjustable） | ||
3. | Slitting way | Drive shear | ||
