Auto Chemiluminescence Analyzer Immunoassay Analyzer

YS-CLIA120 Auto Chemiluminescence analyzer

 Fully automated, random access, STAT priority

Advanced CLIA technology:

Enzymatic chemiluminescence principle

Glow-type luminescence

ALP-AMPPD system, and up to 10-21mol/L high detection sensitivity

Independent magnetic separation washing system, cleanser pre-heating function

 Throughput up to 120 tests/hour

60 sample positions, 24 reagents set position with 24-hours refrigeration

Continuous cuvettes loading

Auto dilution, liquid level detection, collision protection, clot detection

Bi-direction LIS system

Technical Specifications

The machine parameters

 Instrument types: fully automatic tube type chemiluminescence detector

STAT: true random access, special separate tray for STAT samples

Throughput: 120 T/H

Detection principle: enzymatic chemiluminescence

 Detection method

Testing process: one-step, two-step, three-step method, etc

Calibration method: built-in main calibration curves, two-point calibration, six-point calibration

Optical system

•     Independent stability calibration LED light source, ensuring the metering accuracy

•    Independent light testing module to completely eliminate the interference of environment

•    Continuously temperature control to eliminate the influence of temperature fluctuation on the test results

Sample system

•     60 samples positions

•     Sample volume: 5-100u, 1p adjustable

•     Support standard collection tube, vacuum collection tube, and micro blood cup, etc

•     Support automatic sample dilution function for mutiple items dectection

•     Built-in sample bar code reader

Reagent system

•    24 sets of reagent postion

•   Reagent volume(R1, R2, M): 20-150ul, 1pL adjustable

•   24 hours non-stop cooling with peltier element

•   Built-in sample bar code reader

•   Support liquid level detection, collision protection, clot detection and inventory checking

Reaction system

•  Continuous disposable cuvettes loading capacity: 500pcs

•   Automatic loading and unloading Reaction cuvettes with automatic alarm function

•   Direct heating for incubation

 Independent magnetic separation system

•  4-step magnetic separation combined with vortex type resuspension of magnetic particles to ensure cleaning efficiency

•  Array-type surrounding magnetic field design to precisely control the loss of magnetic particles and achieve optimal repeatability of magnetic separation
