Product Description
Ceramic filtration membrane is an alternative core material for membrane separation technology. Ceramic filtration membranes are made of alumina, zirconia, titanium oxide, monox, kaolin and some other main raw materials to form support with porous structure, then functional membrane is prepared by surface coating process, and finally fired at high temperature.
Ceramic Filtration Membrane's Advantages
★ Material excellent - high corrosion resistance, high strength, heat resistance, suitable for solvent or oil, and suit for many kinds of drainage.
★ High flux, the membrane is with high flux, low working pressure and small floor space.
★ Long service life- the ceramic filter membrane system has a longer service life compared with the hollow fiber membrane, so the full life cost is the lowest.
★Energy saving - the membrane surface is not easy to stain, and the replacement structure design.
★ Space saving-High throughput, small area.
★Easy maintenance-Membrane fouling is easy to recover. Air wash, water back wash, medicine washing.
Product Application
The application of ceramic filtration membrane is widely used in MBR (membrane bioreactor) system. MBR is organically integrated by membrane separation process and biochemical system. Compared with the traditional wastewater process, MBR has the many advantages. Thereafter, the MBR processes are used in the areas of water reuse, urban sewage, industrial sewage, wastewater disposal, landfill leachate, drinking water purification etc.
Product Paramenters
Ceramic filtration membrane's Parameters
Model | PCFM-A-20-3-U | PCFM-A-50-3-U | PCFM-A-100-3-U | PCFM-A-1U-3-M | |||
Formation | Plate | ||||||
Filtration | Negative pressure suction filtration | ||||||
Materials | Alpha-Al2O3 | ||||||
Water channel | 43 pcs | ||||||
Channel dimension | 2*3 mm | ||||||
Dimension | 150*510*4 mm | ||||||
Net weight | 0.44 kg | ||||||
Membrane area | 0.15 m2 | ||||||
Max. Pressure | 0.3 MPa | ||||||
Temperature | 10～75 ℃ | ||||||
Nominal pore size | 0.02 µm | 0.05 µm | 0.1 µm | 1 µm | |||
Porosity | 30% | 34% | 35% | 40% | |||
Pure water flux | 20 m3/Day | 20 m3/Day | 100 m3/Day | 200 m3/Day | |||
Bending strength | 80 MPa | 70 MPa | 70 MPa | 70 MPa | |||
Ceramic filtration membrane unit's Parameters
Model | NM303 | NM703 | NM705 | NM710 |
Frame Materials | SUS 304 | SUS 304 | SUS 304 | SUS 304 |
Pipe Materials | UPVC | UPVC | UPVC | UPVC |
PH | 2-12 | 2-12 | 2-12 | 2-12 |
Membrane Dimension (mm) | L310*W150*T4 | L510*W150*T4 | L510*W150*T4 | L510*W150*T4 |
Membrane Material | Al2O3 | Al2O3 | Al2O3 | Al2O3 |
Membrane area (m²) | 3 | 30 | 50 | 100 |
Quantity of Membrane (pcs) | 34 | 204 | 340 | 680 |
Capacity (m³/D) | 2-4 | 20-30 | 40-50 | 80-100 |
MLSS (mg/L) | 3000-12000 | 3000-12000 | 3000-12000 | 3000-12000 |
Confluence Pipe Diameter (mm) | 32 | 50 | 75 | 75 |
Width (mm) | 400 | 665 | 665 | 665 |
Length (mm) | 600 | 760 | 1289 | 1289 |
Height (mm) | 470 | 1978 | 1616 | 2590 |
Net weight (kg) | 28 | 150 | 250 | 450 |
Packaging & Shipping
1. PET film covered--protection
2. Use paper card to separate each layer.
3. Standard export carton or customized.
4. Marked with customer's information or customized.
5. QC Department will check in case the packing method isn't safe enough.
6. By courier, like DHL, UPS, FEDEX, etc. It is door to door, usually it takes 3-5 days to arrive at destination.
7. By air to the airport, usually 5-7 days.
8. By shipping, usually, it will spend 15-30 days to arrive at customer factory.
2. Use paper card to separate each layer.
3. Standard export carton or customized.
4. Marked with customer's information or customized.
5. QC Department will check in case the packing method isn't safe enough.
6. By courier, like DHL, UPS, FEDEX, etc. It is door to door, usually it takes 3-5 days to arrive at destination.
7. By air to the airport, usually 5-7 days.
8. By shipping, usually, it will spend 15-30 days to arrive at customer factory.
Company Introduction
DASEN is a high-tech enterprise engaged in R&D, production and sales of pyrolytic graphite, specialties graphite, die-cutting, silicone pad and plate ceramic membranes. The pyrolytic graphite factory is in Jiangxi; the specialties graphite is in Shandong; the silicone pad factory is in Jiangsu, and the ceramic membrane factory is in Anhui province. And the sales center is in Suzhou, Jiangsu.
Dasen Culture
Corporate vision: lead innovation and services, help customers create competitiveness.
Enterprise mission: cultivate talents and make dedication
Business idea: people-oriented, customer first, continuous creation, pursuit excellence.
Environmental policy: full participation, compliance with laws and regulations, treasure resources.
Certifications
DSN adopt international authoritative quality system certification and safety system certification to ensure the quality and safety of customers. Such as: ISO9001-2015, ISO14001-2015, IATF16949-2016, and many product patents.
FAQ
Q1: Do you have MOQ?
A1: No MOQ for the standard product.
Q2: Do you provide samples?
A2: Yes, we do, and could delivery in 24 hours after confirmation for stock.
And we can offer free samples within one pcs. Just please pay the shipping fee.
Q3: Are you factory or trading company?
A3: We are a professional manufacturer for over 10 years.
Q4: What is the lead time for mass production?
A4: The lead time of mass production is about 5 - 7 days.
Q5: What is your payment method?
A5: Accept TT, Paypal, West Union, L/C, ect.
Q6: Can you provide finished product processing service?
A6: Yes, we can provide the finished product after die-cutting.
