High density heat insulation steel wire braided reinforcement round aluminum silicate ceramic fiber rope

Availabilities

1.Diameter: 3-100mm
2. Tadpole
3. Rope with rectangular section is available upon request.

JINYU ceramic fiber rope is dense, resilient, high performance ceramic fiber material fabricated from ceramic fiber yarn braided around a core of ceramic fiber rope to form a packing in round section. It is widely used for a broad variety of high temperature gasketing, packing and sealing application.

Square braided rope (square packing) is dense, resilient, high performance ceramic fiber material plaited from E-glass, stainless steel wire or high temperature alloy wire inserted ceramic fiber yarn to form a packing in square section.

Twisted rope is fabricated from ceramic fiber yarn twisted left hand/right hand together to form a rope of specified diameters ranging from 3 mm to 50 mm, with glass filament, stainless steel wire or high temperature alloy wire inserted to provide high strength at elevated temperature.

Ceramic fiber rope applications

1. Fireproof wrap and insulation
2. Seals for stoves and ovens
3. Expansion joint packing
4. Bulb in tadpole gaskets
5. Gasket and wrapping material

6. Wick for oil burning apparatus

Cable and wire insulation.

Welding curtains and blankets.

Furnace curtains and heat zone separators

Expansion joint

Fuel line insulation

Welding blankets

High temperature seals and packing in furnace and heaters cord

thermal insulation pipe wrap

furnace door seals jointings.

Classification Temperature    1260°C, 1430°C

Ceramic fiber rope feature:
Low thermal conductivity, low heat tolerance;
Excellent high temperature performance, good thermal shock properties;

Excellent high-temperature insulation performance, long service life;
Good acid, oil and water vapor corrosion;
Good low-temperature and high temperature strength;

Environment friendly;Easy of application

Package:
10kgs/roll, in plastic woven bag of 10kgs net each,
In carton of 20kgs net each.

Ceramic fiber rope technical data
