GTMEDIA V8 Finder Pro +B1:C26B2B1B1:C80

GTMEDIA V8 Finder Pro is a DVB-S2X/S2/S/T2/T/C/ATSC-C and MPEG-2/4 H.264/H.265 (10 bit) compliant handheld combo meter, With its
compact size, light weight, intuitive user's interface, long battery operational hours and rich feature set, the meter provides
all functions needed for installation and verification of digital satellite TV service, antenna signal and cable signal to
residential homes or multi-dwelling units.

Key Features

● 4.3 Inch High Definition TFT LCD Screen

● Fully DVB-S2X/S2/S/T2/T/C/ATSC-C, MPEG-2/MPEG-4 compliant

● Support H.264/H.265(10 Bit) Hardware decoding

● Digital measuring device for signal strength and quality.Supports presetting all satellite information

● Support Loop Search

● Constellation analyzer

● Spectrum analyzer

● Supports scan of Auto, Blind, Manual or NIT

● Sound for Locking Signal

● Auto Calculate Angle of AZ,EL

● Supports DISEQC 1.0/1.1/1.2, Unicable, 0/22kHz Tone

● Speaker Integrated

● Support both AV out and AV in

● Support both HD out

● Supports AHD camera input

● Support compass function

● Support real-time power display, with low power reminder

● Supports Youtube for USB wifi 2.4G

● LNB short protect

● 7.4V/4000mAh Li-ion Battery Included

● Software upgrade via USB port

● Easy to carry

Specifications

TRANSMISSION STANDARDS

DVB-S2X/S2/S,DVB-T2/T,DVB-C/ATSC-C,MPEG-2,MPEG-4,H.264/H.265(10 Bit)

Supports softcam: BISS auto roll, PowerVu auto roll, TNT(19.2E)

Support VCM, ACM, multi-stream, T2MI, Multi-PLP

Supports IKS: CCCAM, NEWCAM, MGCAM

SATELLITE INPUT/DEMODULATION

Connector Type

F Type

Input Frequency

950 to 2150 MHz

Signal Input Level

‐65 to ‐25 dBm

Band Switch Control

22KHz

LNB Supply

13V/18V, Max 350mA

Demodulation Type

DVB-S2 QPSK,DVB-S2 QPSK/8PSK/16APSK/32APSK,
DVB-S2X QPSK/8PSK/16APSK/32APSK/64APSK

Symbol Rate

2

DVB-T2/T/Cable INPUT/DEMODULATION

Connector Type

Female Type

Input Frequency

48 to 862 MHz

Signal Input Level

‐80 dBm(MAX)

ANT Supply

5V DC @ 120mA MAX

Demodulation Type

QPSK,16QAM,32QAM,64QAM,128QAM,256QAM

LCD FEATURES

LCD Type

TFT Transmissive

Number of Dots

800 RGB(H) *480(V)

Active area (W*H)

95.04*53.86mm

AV output interface

Connector Type

3.5 mm jack

Video Output

CVBS

Audio Output

Stereo Audio L/R output

HD output connecter

Format

HD 1.3a

AV input interface

Connector Type

3.5 mm jack

Video Input

CVBS

Audio Input

Stereo Audio L/R input

AHD input interface

Connector Type

BNC Female

Impedance

75Ω

Frequency Range

DC～2GHz

Video input support

NTSC/PAL, 720P/1080P

AUDIO/VIDEO PROCESSING

Video decompression

MPEG-2 MP@HL, MPEG-1 Decoding, MPEG-4 ASP@l5 HD resolution, H.264 / H.265 MP&HP@L4, HW JPEG decoder

Resolving rate

PAL-25 frame@7200*576, NTSC -30 frame@720*480

Singnal compatibility

Support conversion for different video formats

Video Format

4:3, 16:9, By Pan & Scan and Letter Box conversion

Audio Decompression

MPEG-1 Layer I/II, MPEG-2 Layer I/II

Audio Output Mode

Stereo, Mono, R/L

DATA SERVICE PORT

Conector

USB

Data Protocol

USB 2.0 interface

File Management System

NTFS, FAT32, FAT16

File Format

Media:TS,mkv, mp4, avi, flv, f4v, ts, m2ts, mov, 3gp
Audio: wma,mp3
Photo: jpg,jpeg,bmp,img

PVR Option

Support recording TS files

WIFI Option

Support networking via USB WIFI

POWER SUPPLY

Li-Lon Battery

7.4V/4000mAh(The machine behind labeling shall prevail)

Adapter

OUTPUT: DC 9V/2.5A, INTUPT:100～240VAC 50/60Hz(Will be subject to actual configuration)

Power Consumption

Max.10W

PHYSICAL CHARACERSTICS

Product Dimension Size(W*D*H)

123*204*45(mm)

Product Net Weight

0.6kg

Packing box size(W*D*H)

260*200*57(mm)

Package weight

0.85kg

Temperature

Operation 0～+45℃; Storage -10~+60℃

Humidity

20~90%, non-condensed
